CIELO-G Learning Framework

Overview

The CIELO-G Learning Framework is a flexible, plug-and-play framework for Godot 4 that empowers educators and developers to rapidly create educational mini-games. Designed with modularity at its core, the framework provides three extensible game systems, automatic progress tracking, certificate generation, and a rich dialogue system—all without requiring advanced programming knowledge.

Background

Developed as part of an NSF-funded research initiative at the CIELO-G Lab (The University of Texas at El Paso), this framework addresses a critical gap in Earth-science education: the absence of modular, reusable gamification tools that can be easily adapted by educators without extensive technical expertise.

Under the mentorship of Dr. Aaron Velasco, Dr. Katalina Salas, and PhD candidate Marc Garcia, I architected this framework to reduce educational game development time from weeks to hours through scene inheritance patterns and plug-and-play architecture.

The Challenge

Creating educational games typically requires:

• Extensive programming knowledge
• Custom implementation of common features (scoring, progress tracking, feedback)
• Significant time investment for each new game
• Lack of standardization across different educational modules

Architecture Design

I engineered the complete software architecture following modular design patterns in Godot 4 (GDScript):

Core Systems

Game Systems

I designed four extensible game systems with inheritance-based architecture:

1. Explanation System

Narrative-driven content delivery with rich text formatting and character expression states

var dialogue_items: Array[Dictionary] = [
    {
        "expression": expressions["happy"],
        "text": "Welcome to the learning module!",
        "character": bodies["kat"]
    }
]

2. Clickable System

Interactive selection elements for formative assessment (multiple choice, true/false)

@export var is_correct: bool = false  # Mark as correct answer

3. Drag-and-Drop System

Spatial reasoning tasks with kinematic validation (sorting, categorization, placement)

@export var draggables_inside: Array[Area2D] = []  # Expected objects

4. Mix-and-Match System

Graph-based relationship mapping for concept association (connecting pairs, network diagrams)

@export var answers: Array[Area2D] = []      # Correct connections
@export var max_outgoing: int = 1            # Max connections from this
@export var max_incoming: int = 1            # Max connections to this

Key Features

🎯 Modular Game Systems

• Three base systems (Clickable, Drag-and-Drop, Mix-and-Match) that can be inherited and customized
• Plug-and-play architecture: create minigames in Play by inheriting from base systems
• Assets folder structure for organized game-specific resources

📊 Built-in Progress Tracking

• Automatic attempt counting and analytics
• First-try success metrics
• Retry functionality with certificate qualification logic
• Real-time progress indicators

🎓 Certificate Generation

• Evidence-based mastery learning system
• Criteria: 100% first-attempt success, zero retries
• Performance-based feedback reinforcing learning retention
• Player name customization

🎨 Rich Learning Experience

• Explanation/dialogue system with multiple character support
• Character expression states (happy, sad, angry, regular)
• Rich text formatting (wave, shake, rainbow effects)
• Slide support for instructional content
• Shader-based scene transitions

🔧 Developer-Friendly

• Clean, modular codebase with consistent commenting style
• Comprehensive documentation and API guides
• Scene inheritance patterns for rapid prototyping
• Standardized folder structure

Project Structure

CIELO-G_Learning_Framework/
├── Global/                    # Shared resources and scripts
│   ├── Assets/               # Fonts, audio, characters, themes
│   └── Scripts/
│       ├── Managers/         # Core game management (ModuleManager)
│       ├── SetName/          # Player name input
│       ├── ThankYou/         # Completion screens
│       └── Transitions/      # Scene transition effects
│
├── Menu/                      # Main menu and navigation
│   ├── Home/                 # Home screen with play/learn buttons
│   └── MenuBar/              # Progress bar and navigation
│
├── Module/                    # Learning module components
│   ├── Learn/                # Explanation/dialogue system
│   ├── Certificate/          # Certificate generation
│   └── Play/                 # 👉 YOUR MINIGAMES GO HERE!
│       ├── Minigame_1/       # First minigame folder
│       │   ├── Assets/       # Minigame-specific visuals
│       │   └── minigame_1.tscn
│
├── S_Clickable/              # 🎯 Clickable game system (BASE)
│   ├── ClickableSystem.tscn  # Inherit from this
│   └── Prefabs/
│
├── S_DragAndDrop/            # 🎯 Drag-and-drop game system (BASE)
│   ├── DragAndDropSystem.tscn
│   └── Prefabs/
│
└── S_MixAndMatch/            # 🎯 Mix-and-match game system (BASE)
    ├── MixAndMatchSystem.tscn
    └── Prefabs/

Results & Impact

Open Source Publication

• Published on GitHub with MIT License for worldwide educational use
• Comprehensive documentation including README, API guides, and architectural diagrams
• Enables scalable adoption by educators and researchers globally

Development Efficiency

• Educators can create new lessons by simply inheriting scenes and adding content
• No advanced programming required—focus on content, not code

Research Contribution

• Contributes to ongoing research on gamification’s impact on learner motivation in STEM education
• Provides foundation for measuring learning retention through mastery-based criteria
• Demonstrates domain-agnostic approach applicable beyond Earth science

Educational Applications

Technical Challenges & Solutions

Challenge 1: Creating a Truly Modular System

Problem: How to make game systems work across different game types while maintaining consistency?

Solution: Implemented inheritance-based architecture where all games share core manager logic but customize gameplay through scene overrides

# All systems inherit from the same manager
# But customize through exported variables and scene composition

Challenge 2: Progress Tracking Across Minigames

Problem: How to track player progress across multiple minigames and potentially multiple sessions?

Solution: Centralized ModuleManager singleton with state persistence and attempt analytics

# Tracking attempts/results
var _attempts: Dictionary = {}     # scene_path -> attempts count
var _used_retry: bool = false      # any retry pressed?
var _first_try_successes: int = 0  # perfect first attempts
var _completed: int = 0            # finished minigames

Challenge 3: Accessibility for Non-Programmers

Problem: How to make the framework accessible to educators without programming backgrounds?

Solution: Designed intuitive folder structure, export variables for configuration, and comprehensive documentation

Customization Guide

Adding Characters

1. Place character images in Characters
2. Add to ExplanationSystem.gd:

var bodies := {
    "kat":    preload("res://Global/Assets/Characters/kat.png"),
    "sophia": preload("res://Global/Assets/Characters/sophia.png"),
    "new_character": preload("res://Global/Assets/Characters/new.png"),
}

Adding Expressions

1. Place expression images in Expressions
2. Reference in dialogue items:

{
    "expression": expressions["happy"],
    "text": "I'm feeling great!",
    "character": bodies["kat"]
}

Custom Themes

Modify themes in Theme:

• explanation.theme - Learning module theme
• mini_menu.theme - Menu bar theme

Future Enhancements

• Additional game system templates (Quiz, Timeline, Memory Match)
• Multiplayer support for collaborative learning
• Advanced analytics dashboard for educators
• Save/load system for persistent progress across sessions
• Localization support for international adoption
• Mobile touch optimization
• Accessibility features (screen reader, colorblind modes)

Lessons Learned

Throughout this project, I gained valuable insights:

Modularity is key: Designing for extensibility from the start pays dividends when users want to customize

Documentation matters: Clear guides and examples dramatically increase adoption rates

Research context: Understanding pedagogical principles improved design decisions throughout development

Open source impact: Publishing with comprehensive documentation enables community contributions and wider reach

User testing: Early feedback from educators shaped the final architecture significantly

Tech Stack

Links & Resources

• 📦 GitHub Repository
• 📖 Full Documentation
• 🎮 CIELO-G Learning App (Framework in action)
• 🔬 NSF-Funded CIELO-G Lab, UTEP
• 🐛 Report Issues

Acknowledgments

This project was made possible through:

• NSF Funding: Supporting innovative educational technology research
• CIELO-G Lab: Providing resources and research environment
• Mentorship: Dr. Aaron Velasco, Dr. Katalina Salas, and PhD candidate Marc Garcia
• Godot Community: Open-source engine enabling rapid development
• Kenney.nl: Audio assets used in the framework

Project Timeline: August 2025 - Present
Role: Lead Developer & Architect
Organization: NSF-Funded CIELO-G Lab, UTEP
License: MIT (Open Source)
Status: Active development, v1.0 released
